Latest: This case-kit was extended to
315mm length (original 265mm is a little compact size)
What's the DIY case-kit?
- Case-kit is NOT amp-kit, excluding AMP or PSU modules
- Including aluminum encloser, connectors, screws, feet, led and needed internal harness...
- DIY (do-it-yourself) project: All parts packed in bulk, please assemble to the complete amp case by yourself
- Easy to assembly 4 parts (face/rear/top/bottom) to a completed case, so no instruction/guides provided
- Sample assembling by user: Hypex nCore NC252MP (Ghent case Assembly) (by Joseph Tham)
Brief Introduction
- Part number: B265a-M6 (B-series Encloser)
- 100% Aluminum, the best thermal material for amp
- Mono(1CH) case pre-drilled for Nilai500 & PS500DIY
(case-kit excluding any modules)
- Input: we provide two kinds of XLR options：
---Soldering: GP110 Gold-plated XLR socket
---Screw-Type: GP119 Neutrik Gold-plated XLR socket
- Output: GP100 Gold-plated Binding posts (included)
- Solderless: It would be a solderless kit if choosing screw-type XLR
Internal Harness (Free included)
- 1-Mains harness: from AC-Inlet to PS500DIY
- 2-HBUS harness: from PS500DIY to Nilai500
- 3-LED harness: from PS500DIY to LED board
- 4-Signal Input: from XLR to Nilai500 (Mogami OFC W2549 shielded signal cable)
- 5-Speak output: from Nilai500 to Binding Posts (Belden 8471 speaker cable)
Case Specification
- Internal size: 193mm(W) x 58mm(H) x 265mm(D)
- External size: 200mm(W) x 78mm(H) x 276mm(D)
(External size including feet, excluding connectors)
- Case Finish: Full-Black or Silver-Face with Black body
- LED: Blue/Green/Orange/White(Brightness adjustable)
- Face-plate: 8mm thickness
- Top-cover: 3mm thickness, venting holes or slots
- Bottom-plate: 3mm thickness, pre-drilled for modules
- Rear-plate: 3mm thickness, laser imprint text
Packing list (All parts packed
in Bulk)
| Encloser & Parts |
Audio Parts |
Front-Plate x 1
Top-Cover x 1
Bottom-Plate x 1
Rear-Plate x 1
Aluminum Foot x 4
Front-support x 2
Screws set |
AC-Inlet & Switch x 1
XLR socket x 1
Binding Post(Pair) x 1
Dimmer-LED x 1
Internal Harness |
